Spanish Tige en nitinol
Tige en nitinol
Material: NiTi, NiTiFe, NiTiCu, NiTiCo, NiTiCuCr, etc.
Standard: ASTM F2063-12
Nitinol Rod is made from nickel and titanium in a near 1:1 ratio. It has a unique shape memory effect and superelasticity, widely used in medical devices, aerospace, robotics, and consumer electronics. As a leading supplier and manufacturer of premium nitinol alloys products, Heeger Metal leverages advanced technology to deliver high-quality nitinol rods for various applications.
Ou envoyez-nous un courriel à l'adresse suivante max@heegermaterials.com.Nitinol Rod Data Sheet
| Matériau : | NiTi, NiTiFe, NiTiCu, NiTiCo, NiTiCuCr, etc. |
| Standard : | ASTM F2063-12 |
| Diameter: | >0.2″, or customized |
| Available Shape: | Rod, Bar, Rectangular bar, Threaded Rod, or customized |
| Surface: | Black, Pickled, or Polished |
| Af Temperature: | -10 ℃ to 120 ℃ |
What Is The Nitinol Alloy?
Nitinol, also called NiTi shape memory alloy, is a metal alloy composed of nickel and titanium, typically in a near 1:1 ratio. It has a unique shape-memory effect and superelasticity, allowing it to return to a preset shape when heated or recover its original form after significant deformation. It offers an expansion rate of over 20%, a fatigue life of 107 cycles, damping properties ten times greater than regular springs, and superior corrosion resistance compared to stainless steel. Due to its excellent biocompatibility, corrosion resistance, and mechanical properties, Nitinol alloy is widely used in medical devices (e.g., stents and orthodontic wires), aerospace, industrial manufacturing, and consumer products.
Tige en nitinol
Nitinol Rod is known for its unique shape memory effect and superelasticity. At room temperature, the Nitinol rod can undergo significant deformation and fully recover its original shape, while heating it to a specific temperature triggers its ability to “remember” and return to a pre-set form. It also has excellent biocompatibility, corrosion resistance, and high fatigue life, making it widely applied in medical devices. There are two main types of superelastic and shape-memory materials based on their transition temperature. HM can offer customized solutions for diameter and surface state according to specific requirements.
Nitinol Rod Mechanical Properties: Superelastic Grades
| Cold Worked | Superelastic | |||||||
| Grade | Ingot As(℃) | Min. Uts(psi) | Élongation(%) | Min. Uts(psi) | Élongation(%) | Loading Plateau(ksi) | Unloading Plateau(ksi) | Active Af (℃) |
| Nitinol #1 | -35 to -10 | 220,000 | >4 | 180,000 | >10 | >70,000 | >20,000 | +10 to +18 |
| Nitinol #2 | -45 to -15 | 250,000 | >4 | 210,000 | >10 | >80,000 | >35,000 | 0 to +18 |
| Nitinol #4 | -10 to +10 | 220,000 | >4 | 180,000 | >10 | >65,000 | >7,000 | +14 to +22 |
| Nitinol #9 | ≥ +35 | 220,000 | >4 | 160,000 | >10 | >75,000 | >25,000 | ≤0 |
Nitinol Rod Mechanical Properties: Shape-Memory Grades
| Cold Worked | Shape-memory | |||||||
| Grade | Ingot As(℃) | Min. Uts(psi) | Élongation(%) | Min. Uts(psi) | Élongation(%) | Loading Plateau(ksi) | Unloading Plateau(ksi) | Active Af (℃) |
| Nitinol #5 | ≥ +85 | 220,000 | >3 | 160,000 | >10 | N/A | N/A | ≥ +85 |
| Nitinol #6 | +35 to +85 | 220,000 | >3 | 160,000 | >10 | N/A | N/A | +40 to +80 |
| Nitinol #8 | +10 to +35 | 220,000 | >3 | 160,000 | >10 | N/A | N/A | +22 to +40 |
Nitinol Rod Material Chemical Composition
| Chemical Composition (wt%) | ||||
| Fe | Ni | Cr | Cu | Nb |
| ≤0.05 | 54.5-57.0 | ≤0.01 | ≤0.01 | ≤0.025 |
| C | Ti | Co | N+O | H |
| ≤0.05 | Balanced | ≤0.05 | ≤0.050 | ≤0.005 |
Nitinol Rod Advantages
- Shape Memory
- Superelasticity
- Sensitivity to Oral Temperature Changes
- Excellent Corrosion Resistance
- Anti-Toxicity
- Gentle Orthodontic Force
- Good Damping Characteristics
Nitinol Rod Surface Finish
- Noir: La surface est "telle que sertie" ou "telle qu'étirée", conservant une couche de lubrifiants et d'oxydes de traitement.
- Nettoyé: La surface est nettoyée chimiquement pour éliminer tous les lubrifiants et oxydes.
- Sol: La surface est décentrée afin d'éliminer tous les revêtements et d'obtenir un contrôle précis des dimensions.
Nitinol Rod Applications
Domaine médical:
- Orthopedic Implants: Nitinol bars are widely used in orthopedics, such as for spinal fixation, fracture repair, and artificial joints.
- Dental Equipment: Nitinol bars make dental orthodontic wires and endodontic tools, offering excellent flexibility and shape memory.
- Vascular Stents: Nitinol bars can be made into vascular stents, used to treat arterial stenosis or aneurysms.
Industrial Applications:
- Aerospace Components: Nitinol bars are used in aerospace for parts like temperature sensors and shape memory components.
- Robotics: Nitinol bars have significant applications in robotics, enabling the creation of flexible robotic hands and bionic structures.
- Sensors and Actuators: Nitinol bars can be used to manufacture temperature sensors and thermal actuators, widely used in automatic control systems.
Consumer Products:
- Eyeglass Frames: Nitinol bars are used to make eyeglass frames with shape memory properties, allowing them to return to their original shape after being bent.
- Elastic Jewelry: Nitinol bars can be made into jewelry that is both elastic and durable, adapting to various shapes and sizes.
- Sports Equipment: Nitinol bars are used to produce high-performance sports equipment, such as golf clubs and fishing rods.
Nitinol Rod Packaging
Nitinol Rod products are carefully placed in wooden cases or cartons, with additional support from soft materials, to prevent shifting during transportation. This packaging method guarantees the integrity of the products throughout the delivery process.
