Alliage de platine et d'iridium Plaque/Teinture/Disque
Alliage de platine et d'iridium Plaque/Teinture/Disque
Matériau : PtIr5, PtIr10, PtIr15, PtIr20, PtIr25
Platinum Iridium Alloy Plate/Sheet/Disc is made from a high-quality blend of platinum and iridium, possessing exceptional durability, corrosion resistance, and thermal stability. It is widely applied in electrochemical cells, high-precision instruments, aerospace components, and medical devices. As a leading supplier and manufacturer of premium platinum products, Heeger Metal leverages advanced technology to deliver high-quality platinum iridium alloy plates, sheets, and discs for various applications.
Ou envoyez-nous un courriel à l'adresse suivante sales@heegermaterials.com.
Platinum Iridium Alloy Plate/Sheet/Disc Data Sheet
| Code de référence : | HMPL2692 |
|---|---|
| Matériau : | PtIr5, PtIr10, PtIr15, PtIr20, PtIr25 |
| La pureté : | 99.95% - 99.99% |
| Densité : | 21,56 g/cm3 |
| Tempérer : | Recuit ou non recuit |
Platinum Iridium Alloy Plate/Sheet/Disc Description
Platinum Iridium Alloy combines the best properties of both metals, offering exceptional durability and stability. Platinum Iridium Alloy Plate/Sheet/Disc has superior resistance to corrosion, high temperatures, and chemical reactions, making it widely used in precision instruments, electrochemical cells, and various scientific research applications. Heeger Metal can supply high-quality platinum iridium alloy plates, sheets, and discs in various sizes and customized designs for multiple industrial and research applications.
Pt-Ir Alloy Plate
Pt-Ir Alloy Sheet
Pt-Ir Alloy Disc
Platinum Iridium Alloy Plate/Sheet/Disc Specifications
| Type | Point de fusion (℃) | Densité (g/cm³) | HV (état doux) | HV (état dur) | Résistance à la traction (MPa) | Résistivité électrique (µΩ-cm) à 20℃ |
|---|---|---|---|---|---|---|
| Pt-Ir5% | 1790 | 21.49 | 90 | 140 | 274 | 19.0 |
| Pt-Ir10% | 1800 | 21.53 | 130 | 230 | 382 | 24.5 |
| Pt-Ir20% | 1840 | 21.81 | 200 | 300 | 539 | 32.0 |
| Pt-Ir25% | 1840 | 21.72 | 200 | 300 | 238 | 33.0 |
Platinum Iridium Alloy Plate/Sheet/Disc Applications
- Electrochemical Devices: Used in electrodes, fuel cells, and electrolysis equipment due to their excellent electrochemical properties.
- Composants aérospatiaux: Employed in aerospace applications where high temperatures and oxidation resistance are critical.
- Dispositifs médicaux: Used in implants and devices that require biocompatibility and resistance to body fluids.
- Instruments de précision: Applied in high-precision measurement devices, such as thermocouples and other scientific instruments, because of their stability and high-temperature performance.
- Catalysts: Utilized in catalytic processes, especially in chemical production and environmental protection, due to their excellent catalytic activity.
Platinum Iridium Alloy Plate/Sheet/Disc Packaging
Platinum Iridium Alloy Plate/Sheet/Disc is carefully placed in wooden cases or cartons with additional soft materials to support and prevent shifting during transportation. This packaging method guarantees the integrity of the products throughout the delivery process.
Propriétés de l'alliage platine-iridium
Télécharger
Obtenir un devis
Nous vérifierons et vous contacterons dans les 24 heures.
Other Plate/Sheet/Disc Products
Heeger Metal offers a wide range of custom plate, sheet, and disc products, available in materials like tungsten, molybdenum, titanium, and nickel alloys. Our precision-engineered products are ideal for various industrial applications, including aerospace, electronics, and energy. Whether you need flat plates, thin sheets, or precision-cut discs, we provide tailored solutions with exceptional strength, durability, and high-performance characteristics to meet your specific requirements.
