Iridium Tube/Pipe

Iridium Tube/Pipe

Iridium Tube/Pipe

Purity: >99.9%

  • Custom sizes and standard sizes in stock
  • Quick Lead Time
  • Competitive Price
5 星级
5 星级
5 星级
5 星级
5 星级

Iridium Tube/Pipe is a high-performance component made from a high-purity iridium up to 99.95%, offering excellent high-temperature strength and corrosion resistance. As a leading supplier and manufacturer of premium iridium products, Heeger Metal leverages advanced technology to deliver high-quality iridium tubes and pipes for various applications.

Get a Quote
Or email us at max@heegermaterials.com.

Iridium Tube/Pipe Data Sheet

CAS:7439-88-5
Purity:>99.9%
Density:22.4 g/cm3
Melting Point:2410℃
Boiling Point:4130℃
Dimension:OD: 20-160 mm
Wall Thickness: 2-20 mm
Customized according to specific requirements
Temper:Annealed or Unannealed

Iridium Tube/Pipe Description

Iridium (Ir) is a dense, corrosion-resistant, and highly durable metal. Iridium Tube/Pipe is made from high-purity iridium, exhibiting superior high-temperature resistance, corrosion resistance, and conductivity. Due to its high melting point and resistance to oxidation, Iridium tubes/pipes are perfect for high-temperature processes, vacuum systems, and as part of catalytic converters. Heeger Metal can supply high-quality iridium tubes and pipes with various specifications and customized solutions to suit industrial and research applications, ensuring optimal performance and cost-effectiveness.

  • Iridium Tube/Pipe

Iridium Tube/Pipe Chemical Composition

Impurities（≤%）
PtRuRhPdAuAgCuFeNi
0.020.020.020.010.010.0050.0050.0050.005
AlPbMnMgSnSiZnCa
0.0050.0050.0050.0050.0050.0050.0050.005

Iridium Tube/Pipe Advantages

  • Excellent corrosion resistance
  • High melting point
  • Oxidation resistance
  • High strength
  • High precision and customization

Iridium Tube/Pipe Applications

  • Aerospace Industry: Used in spacecraft components, rocket engines, and exhaust systems due to their ability to withstand extreme temperatures and harsh conditions.
  • Chemical Processing: Employed in chemical reactors and systems that deal with highly corrosive substances, as iridium resists oxidation and degradation.
  • Electronics: Used in vacuum systems, as well as in components of electron microscopes and other high-precision instruments.
  • Catalytic Converters: Iridium pipes are used in catalytic converters for chemical reactions at high temperatures, especially in the automotive industry.
  • Medical Equipment: Used in medical devices that require high resistance to corrosion and high temperatures, such as in certain surgical tools or equipment exposed to high sterilization processes.

Iridium Tube/Pipe Packaging

Iridium Tube/Pipe is carefully placed in wooden cases or cartons with additional soft materials to support and prevent shifting during transportation. This packaging method guarantees the integrity of the products throughout the delivery process.

Metal Packing

Iridium Properties

ElementValue
Atomic number77
Crystal structureFace centred cubic
Electronic structureXe 4f¹⁴ 5d⁷ 6s²
Valences shown3, 4
Atomic weight( amu )192.22
Thermal neutron absorption cross-section( Barns )425
Photo-electric work function( eV )4.6
Natural isotope distribution( Mass No./% )191/ 37.3
Natural isotope distribution( Mass No./% )193/ 62.7
Atomic radius – Goldschmidt( nm )0.135
ElementValue
Material conditionSoft
Material conditionHard
Poisson’s ratio0.26
Poisson’s ratio0.26
Bulk modulus( GPa )371
Bulk modulus( GPa )371
Tensile modulus( GPa )528
Tensile modulus( GPa )528
Hardness – Vickers( kgf mm⁻² )650
Hardness – Vickers( kgf mm⁻² )200-300
Tensile strength( MPa )550-1100
Tensile strength( MPa )1200
ElementValue
Electrical resistivity( µOhmcm )5.1@20@20°C
Superconductivity critical temperature( K )0.11
Temperature coefficient( K⁻¹ )0.0045@0-100°C
Thermal emf against Pt (cold 0C – hot 100C)( mV )0.65
ElementValue
Boiling point( C )4130
Density( gcm⁻³ )22.4@20°C
ElementValue
Melting point( C )2410
Latent heat of evaporation( J g⁻¹ )3186
Latent heat of fusion( J g⁻¹ )135
Specific heat( J K⁻¹ kg⁻¹ )133@25°C
Thermal conductivity( W m⁻¹ K⁻¹ )147@0-100°C
Coefficient of thermal expansion( x10⁻⁶ K⁻¹ )6.8@0-100°C

Download

Get A Quote

We will check and get back to you in 24 hours.

To customize your iridium tube or iridium pipe, please provide the following details:

  1. Dimensions (Outer Diameter, Inner Diameter, Wall Thickness, Length)
  2. Tolerances (allowable variations in diameter and length)
  3. Purity (Specify the purity of material required.)
  4. Surface Finish (polished, rough, oxide-coated, etc.)
  5. Quantity of the products you need
  6. Alternatively, you can provide a drawing with your specifications.

Once we have these details, we can provide you with a quote within 24 hours.

We carry a wide variety of iridium products in stock, and for these, there is generally no minimum order requirement. However, for custom orders, we typically set a minimum order value of $200. The lead time for stock items is usually 1-2 weeks, while custom orders usually take 3-4 weeks, depending on the specifics of the order.

DFARS (Defense Federal Acquisition Regulation Supplement) compliance is primarily concerned with the sourcing of materials for defense-related applications in the United States. According to DFARS, certain materials used in defense must be sourced from the United States or qualifying countries.

If you have specific iridium materials that are subject to DFARS, please let us know in advance and we will confirm.

At Heeger Metal, we take this responsibility seriously. We adhere to all applicable laws and regulations, including Section 1502 of the Dodd-Frank Act. Our company operates with a strict code of ethics and is committed to only partnering with suppliers who share our dedication to responsible sourcing. We support the initiatives and programs aimed at promoting “conflict-free” supply chains and work diligently to ensure that our products meet these standards.

Iridium tube/pipe is primarily used in high-temperature crucibles, chemical processing equipment, and aerospace components due to its extreme corrosion resistance.

Standard diameters range from 1mm to 5mm, with wall thicknesses from 0.1mm to 5mm. Customized sizes are available upon request.

Iridium tube/pipe can operate continuously at temperatures up to 2000℃ in inert atmospheres.

Heeger Metal, established in 2016 in Colorado, USA, is a specialized supplier and manufacturer of iridium products. With extensive expertise in supply and export, we offer competitive pricing and customized solutions tailored to specific requirements, ensuring outstanding quality and customer satisfaction. As a professional provider of refractory metals, specialty alloys, spherical powders, and various advanced materials, we serve the research, development, and large-scale industrial production needs of the scientific and industrial sectors.
