Molybdenum Powder

Purity: 99.95%-99.99%

Material: Pure Mo₃₆₁, MoTZM (Mo₃₆₄), Mo-Lanthanoxid (ML)

Custom sizes and standard sizes in stock
Quick Lead Time
Competitive Price

Molybdenum Powder is made of high-purity molybdenum material, exhibiting high surface area and wide ranges of particle size distribution. It is highly versatile in the fields of metallurgy and materials science. As a leading supplier and manufacturer of premium molybdenum products, Heeger Materials leverages advanced technology to deliver high-purity molybdenum and molybdenum alloy powders for wide ranges of applications.

Get a Quote

Or email us at sales@heegermaterials.com.

Molybdenum Powder Data Sheet

Reference:	HMMO1086
Material:	Pure Mo₃₆₁, MoTZM (Mo₃₆₄), Mo-Lanthanoxid (ML)
Purity:	99.95%-99.99%
Shape:	Irregular or Spherical
Particle Size:	FSSS 1-10 μm, 0-25 μm, 15-53 μm, 53-105 μm, 53-150 μm, or sieve as required

Molybdenum Powder

Molybdenum is a silver-grey metal with a melting point of 2623 ℃ and a density of 10.2 g/cm³. It is one of the commercially available metals with the lowest coefficient of thermal expansion. Molybdenum Powder is commonly produced by reducing ammonium paramolybdate or calcined MoO3 with hydrogen. The oxygen content can be reduced to lower levels through specific reduction conditions. HM can supply high-quality irregular and spherical molybdenum powder with particle sizes from coarse to ultra-fine.

Molybdenum Powder
Irregular Molybdenum Powder SEM
Molybdenum Spherical Powder SEM

Molybdenum Powder Specifications

Product		HM-Mo-1	HM-Mo-2	HM-Mo-3
Mo content (%)		≥99.95	≥99.90	≥99.80
Impurities content (≤%)	Cd	0.001	—	0.001
	Fe	0.005	0.006	0.030
	Al	0.0015	0.002	0.005
	Bi	0.0010	—	0.001
	C	0.0060	0.010	0.020
	Ca	0.0020	0.002	0.004
	Sb	0.0010	—	0.001
	Cr	0.0030	—	—
	Cu	0.0010	0.001	—
	Mg	0.0020	0.003	0.005
	Mn	0.0005	—	—
	Ni	0.0010	0.003	0.005
	O	0.1500	0.25	0.25
	P	0.0010	0.001	0.005
	Pb	0.0010	—	0.001
	Sn	0.0010	—	0.001
	Si	0.0020	0.003	0.010
	Ti	0.0010	—	—
	W	0.0150	—	—

Molybdenum Powder Features

High-temperature strength and creep resistance
Excellent corrosion resistance
Good thermal and electrical conductivity
Low coefficient of thermal expansion
High hardness and wear resistance
Good lubricity in the vulcanizing atmosphere
Available in various particle size distributions

Molybdenum Powder Production Method

Molybdenum Powder can be produced using various methods, with hydrogen reduction being the most commonly employed industrial process. This method allows precise control over the powder’s morphology, particle size, and purity.

Hydrogen Reduction: Reduction of molybdenum trioxide with hydrogen to produce molybdenum powder.
Thermal Decomposition: Heating molybdenum compounds such as ammonium molybdate to form molybdenum oxide followed by hydrogen reduction.
Electrolytic Production: Molybdenum powder precipitates are produced by aqueous electrolytic precipitation from an acidic molybdate solution.
Calcium Thermal Reduction: Reduction of molybdenum trioxide using calcium.

Molybdenum Powder Applications

Powder Metallurgy: Molybdenum powder is an important raw material for producing molybdenum alloys and molybdenum products, and is widely used to manufacture high-strength, high-temperature alloys and corrosion-resistant alloys.
Electronic Industry: Molybdenum powder is also used to manufacture electronic components such as electrodes, semiconductor devices, and electrode wires for EDM machines.
Chemical Industry: Molybdenum powder is used as a catalyst and corrosion-resistant material in the chemical and petroleum industries.
Aerospace: Molybdenum powder is used to manufacture high-temperature components such as gas turbine blades and guide vanes for jet engines.
Glass and Ceramics Industry: Molybdenum powder is also used to manufacture heaters for high-temperature furnaces and electrodes for glass-melting furnaces.

Molybdenum Powder Packaging

The Molybdenum Powder is carefully placed in wooden cases or cartons with additional support from soft materials to prevent any shifting during transportation. This packaging method guarantees the integrity of the products throughout the delivery process.

Molybdenum Properties

Item	Value
Atomic number	42
Crystal structure	Body centred cubic
Electronic structure	Kr 4d⁵ 5s¹
Valences shown	2, 3, 4, 5, 6
Atomic weight( amu )	95.94
Thermal neutron absorption cross-section( Barns )	2.65
Photo-electric work function( eV )	4.2
Natural isotope distribution( Mass No./% )	95/ 15.9
Natural isotope distribution( Mass No./% )	96/ 16.7
Natural isotope distribution( Mass No./% )	98/ 24.1
Natural isotope distribution( Mass No./% )	97/ 9.6
Natural isotope distribution( Mass No./% )	92/ 14.8
Natural isotope distribution( Mass No./% )	94/ 9.3
Natural isotope distribution( Mass No./% )	100/ 9.6
Atomic radius – Goldschmidt( nm )	0.14
Ionisation potential( No./eV )	2/ 16.15
Ionisation potential( No./eV )	5/ 61.2
Ionisation potential( No./eV )	Jun-68
Ionisation potential( No./eV )	1/ 7.10
Ionisation potential( No./eV )	3/ 27.2
Ionisation potential( No./eV )	4/ 46.4

Item	Value
Material condition / Temper	Annealed (Soft)
Material condition / Temper	Un-annealed (Hard)
Poisson’s ratio	0.293
Poisson’s ratio	0.293
Bulk modulus( GPa )	261.2
Bulk modulus( GPa )	261.2
Tensile modulus( GPa )	324.8
Tensile modulus( GPa )	324.8
Hardness – Vickers( kgf mm⁻² )	250
Hardness – Vickers( kgf mm⁻² )	200
Tensile strength( MPa )	485-550
Tensile strength( MPa )	620-690
Yield strength( MPa )	550
Yield strength( MPa )	415-450

Item	Value
Electrical resistivity( µOhmcm )	5.7@20@20°C
Superconductivity critical temperature( K )	0.915
Temperature coefficient( K⁻¹ )	0.00435@0-100°C
Thermal emf against Pt (cold 0C – hot 100C)( mV )	1.45

Item	Value
Boiling point( °C)	4612
Density( gcm⁻³ )	10.22@20°C

Item	Value
Melting point( °C )	2617
Latent heat of evaporation( J g⁻¹ )	6153
Latent heat of fusion( J g⁻¹ )	290
Specific heat( J K⁻¹ kg⁻¹ )	251@25°C
Thermal conductivity( W m⁻¹ K⁻¹ )	138@0-100°C
Coefficient of thermal expansion( x10⁻⁶ K⁻¹ )	5.1@0-100°C

Download

SAFT DATA SHEET (SDS) – Molybdenum Powder

Get A Quote

We will check and get back to you in 24 hours.

To customize your molybdenum powder, please provide the following details:

Purity
Particle Size
Quantity of the powder you need
Applications (We can also make recommendations based on your specific needs.）

Once we have these details, we can provide you with a quote within 24 hours.

We carry a wide variety of molybdenum and molybdenum alloy products in stock, and for these, there is generally no minimum order requirement. However, for custom orders, we typically set a minimum order value of $200. The lead time for stock items is usually 1-2 weeks, while custom orders usually take 3-4 weeks, depending on the specifics of the order.

DFARS (Defense Federal Acquisition Regulation Supplement) compliance is primarily concerned with the sourcing of materials for defense-related applications in the United States. According to DFARS, certain materials used in defense must be sourced from the United States or qualifying countries.

If you have specific molybdenum materials that are subject to DFARS, please let us know in advance and we will confirm.

At Heeger Materials Inc., we take this responsibility seriously. We adhere to all applicable laws and regulations, including Section 1502 of the Dodd-Frank Act. Our company operates with a strict code of ethics and is committed to only partnering with suppliers who share our dedication to responsible sourcing. We support the initiatives and programs aimed at promoting “conflict-free” supply chains and work diligently to ensure that our products meet these standards.

Heeger Materials Inc., established in 2016 in Colorado, USA, is a specialized supplier and manufacturer of tantalum and tantalum alloys. With extensive expertise in supply and export, we offer competitive pricing and customized solutions tailored to specific requirements, ensuring outstanding quality and customer satisfaction. As a professional provider of refractory metals, specialty alloys, spherical powders, and various advanced materials, we serve the research, development, and large-scale industrial production needs of the scientific and industrial sectors.
