Tungsten Rhenium Alloy

Tungsten Rhenium Alloy

Tungsten Rhenium Alloy

Material: WRe3%, WRe5%, WRe25%, WRe26%

Reference: HMWW1121

  • Custom sizes and standard sizes in stock
  • Quick Lead Time
  • Competitive Price
5 star rating
5 star rating
5 star rating
5 star rating
5 star rating

Tungsten Rhenium Alloy is a high-performance material made from tungsten and rhenium, with rhenium content ranging from 3% to 26%. Different compositions offer varying characteristics and are suited to specific applications. As a leading supplier and manufacturer of premium tungsten products, Heeger Materials leverages advanced technology to deliver high-purity tungsten rhenium alloy products for wide ranges of applications.

Get a Quote
Or email us at sales@heegermaterials.com.

Tungsten Rhenium Alloy Data Sheet

Reference:HMWW1121
Material:WRe3%, WRe5%, WRe25%, WRe26%
Temper:Annealed and Unannealed

Tungsten Rhenium Alloy

Tungsten Rhenium Alloy is a high-density tungsten-based alloy with rhenium added in varying proportions, typically at 1%, 3%, 5%, 20%, and 26%. It exhibits excellent properties, including high melting point, high strength, hardness, plasticity, high electrical resistivity, etc. HM provides high-precision tungsten rhenium alloy products in various forms, including rods, plates, sheets, bars, tubes, blocks, pellets, wires, and discs, all crafted to ensure exceptional quality and customer satisfaction. We manufacture large, complex parts using isostatic pressure molding technology, while smaller parts are produced through extrusion, molding, and injection molding techniques. Additionally, rods and sheets are fabricated using forging and rolling processes.

  • Tungsten Rhenium Alloy Plate
    W-Re Alloy Plate
  • Tungsten Rhenium Alloy Rod
    W-Re Alloy Rod
  • Tungsten Rhenium Alloy Tube
    W-Re Alloy Tube
  • Tungsten Rhenium Alloy Thermocouple Wire
    W-Re Alloy Thermocouple Wire
  • Tungsten Rhenium Alloy Sputtering Target
    W-Re Alloy Sputtering Target

Tungsten Rhenium Alloy Material Properties

ItemWW-3ReW-25ReW-26ReRe
Melting Point (℃)34103360310029503170
Density (g/cm3)19.319.419.6519.6621.02
Resistivity(uΩ.cm)20 ℃5.59.727.929.619.8
1000 ℃36.237.854.755.562.0
1500 ℃5253.568.570.682.0
2000 ℃66.069.082.085.0150.0
Microhardness (MPa)Machined3423-39233923-43255394-78455394-78454903-7845
1000 ℃ annealed8342844-30403579-36783678-37761412
Tensile Strength (MPa)Machined19503300240024102256-2452
1400 ℃ annealed1650175019501970
1600 ℃ annealed1200162018101800
1800 ℃ annealed850142016001620
Elongation (%)Machined1-21-22-32-31-2
1400 ℃ annealed1-22-315-2015-2020-25
1600 ℃ annealed1-25-1018-2218-2218-20
1800 ℃ annealed1-210-1517-1917-1910-15
Recrystallization Rate11001500180017801500

Tungsten Rhenium Alloy Products List

ProductMaterial TypeDimensions
Tungsten Rhenium Thermocouple WireWRe3/25, WRe5/26Diameter: 0.1mm, 0.2mm, 0.25mm, 0.3mm, 0.35mm, 0.5mm
Tungsten Rhenium Alloy WireWRe3%, WRe5%, WRe25%, WRe26%Diameter: 0.1mm, 0.2mm, 0.25mm, 0.3mm, 0.35mm, 0.5mm
Tungsten Rhenium Alloy Rod/BarWRe3%, WRe5%, WRe25%, WRe26%Diameter: 1-35 mm
Tungsten Rhenium Alloy Sheet/PlateWRe3%, WRe5%, WRe25%, WRe26%Thickness: >0.2 mmWidth: 10-350 mmLength: <600 mm
Tungsten Rhenium Alloy TubeWRe3%, WRe5%, WRe25%, WRe26%Customized according to specific requirements.
Tungsten Rhenium Alloy PowderWRe0.1-26%-200 mesh, or customized
Tungsten Rhenium Alloy Spherical PowderWRe3%, WRe5%, WRe25%, WRe26%2.0-4.0 μm, or customized
Tungsten Rhenium Alloy Sputtering TargetWRe3%, WRe5%, WRe25%, WRe26%Customized according to specific requirements.

Tungsten Rhenium Alloy Features

  • High Melting Point: Tungsten rhenium alloy has a very high melting point, suitable for use at extremely high temperatures.
  • High Strength and Hardness: Tungsten rhenium alloy can still maintain excellent mechanical strength and hardness under a high-temperature environment.
  • High Plasticity: Compared with pure tungsten, tungsten rhenium alloy has better ductility and processing performance.
  • High Recrystallization Temperature: Tungsten rhenium alloy has a high recrystallization temperature and can maintain a stable crystal structure at high temperatures.
  • Low Toughness and Brittle Transition Temperature: Tungsten rhenium alloy can still maintain good toughness at low temperatures, and is not easy to brittle crack.

Tungsten Rhenium Alloy Production Process

  • Mixing: The tungsten powder is mixed with rhenium in the desired proportions.
  • Pressing: The mixed powder is pressed into the desired preliminary shape, such as cylinders, blocks, etc.
  • Sintering: The pressed parts are sintered at high temperatures, forming a dense solid material.
  • Annealing: The sintered products undergo an annealing process to remove internal stresses and improve toughness and ductility.
  • Machining: Precision machining processes, such as turning, milling, and grinding, are applied to the sintered parts to achieve final dimensions and shapes.
  • Heat Treatment: The alloy undergoes additional heat treatment to optimize properties such as hardness, strength, or other physical characteristics.
  • Surface Treatment: If required, surface treatments (such as coating, passivation, etc.) are applied to enhance corrosion resistance, hardness, or other properties.

Tungsten Rhenium Alloy Machining Service

HM has advanced machining centers equipped with various high-precision processing equipment, enabling us to offer multiple machining services such as turning, milling, grinding, and drilling. Whether for large-scale production or customized small-batch orders, we guarantee high precision and performance to meet customer’s specific requirements. The following are methods we will use during processing:

  • Isostatic Pressing
  • Forging
  • Extrusion
  • Molding
  • Injection Molding
  • Rolling
  • Electrical Discharge Machining (EDM)
  • Milling
  • Turning

Tungsten Rhenium Alloy Applications

  • Aerospace: Tungsten rhenium alloy can be used to manufacture rocket nozzles, spacecraft parts, and other high-temperature structural materials.
  • Electronic Technology: Tungsten rhenium alloy can be used for the core metal of electron tube filament, gate filament, and direct heat cathode.
  • Nuclear Technology: Tungsten rhenium alloy can be used as high-temperature materials in nuclear reactors.
  • Temperature Measurement: tungsten rhenium thermocouples are widely used in high-temperature measurement because of their high thermal potential and sensitivity.
  • Medical Devices: tungsten rhenium alloy can also be used to manufacture high-temperature sterilization equipment and other high-temperature medical devices.

Tungsten Rhenium Alloy Packaging

The Tungsten Rhenium Alloy is carefully placed in wooden cases or cartons with additional support from soft materials to prevent any shifting during transportation. This packaging method guarantees the integrity of the products throughout the delivery process.

Metal Packing

Tungsten Properties

ItemValue
Atomic number74
Crystal structureBody centred cubic
Electronic structureXe 4f¹⁴ 5d⁴ 6s²
Valences shown2,3,4,5,6
Atomic weight( amu )183.85
Thermal neutron absorption cross-section( Barns )18.5
Photo-electric work function( eV )4.55
Natural isotope distribution( Mass No./% )183/ 14.3
Natural isotope distribution( Mass No./% )182/ 26.3
Natural isotope distribution( Mass No./% )186/ 28.6
Natural isotope distribution( Mass No./% )180/ 0.1
Natural isotope distribution( Mass No./% )184/ 30.7
Atomic radius – Goldschmidt( nm )0.141
Ionisation potential( No./eV )1/ 7.98
Ionisation potential( No./eV )2/ 17.7
ItemValue
Material conditionAnnealed (Soft)
Material conditionUn-annealed (Hard)
Poisson’s ratio0.28
Poisson’s ratio0.28
Bulk modulus( GPa )311
Bulk modulus( GPa )311
Tensile modulus( GPa )411
Tensile modulus( GPa )411
Hardness – Vickers( kgf mm⁻² )360
Hardness – Vickers( kgf mm⁻² )500
Tensile strength( MPa )550-620
Tensile strength( MPa )1920
Yield strength( MPa )550
ItemValue
Electrical resistivity( µOhmcm )5.4@20@20°C
Superconductivity critical temperature( K )0.0154
Temperature coefficient( K⁻¹ )0.0048@0-100°C
Thermal emf against Pt (cold 0C – hot 100C)( mV )1.12
ItemValue
Boiling point( °C )5660
Density( gcm⁻³ )19.3@20°C
ItemValue
Melting point( °C )3410
Latent heat of evaporation( J g⁻¹ )4009
Latent heat of fusion( J g⁻¹ )192
Specific heat( J K⁻¹ kg⁻¹ )133@25°C
Thermal conductivity( W m⁻¹ K⁻¹ )173@0-100°C
Coefficient of thermal expansion( x10⁻⁶ K⁻¹ )4.5@0-100°C

Download

Get A Quote

We will check and get back to you in 24 hours.

To customize your tungsten rhenium alloy products, please provide the following details:

  1. Alloy Composition: Specify the alloy composition and ratio.
  2. Density: Specify the density you need
  3. Dimensions ＆ Shape: Provide size and shape requirements.
  4. Tolerance ＆ Precision: Define acceptable tolerances.
  5. Surface Finish: Specify surface treatment (e.g., polished or coating).
  6. Quantity of the products you need
  7. Applications (We can also make recommendations based on your specific needs.)
  8. Alternatively, you can provide a drawing with your specifications.

Once we have these details, we can provide you with a quote within 24 hours.

We carry a wide variety of tungsten and tungsten alloy products in stock, and for these, there is generally no minimum order requirement. However, for custom orders, we typically set a minimum order value of $200. The lead time for stock items is usually 1-2 weeks, while custom orders usually take 3-4 weeks, depending on the specifics of the order.

DFARS (Defense Federal Acquisition Regulation Supplement) compliance is primarily concerned with the sourcing of materials for defense-related applications in the United States. According to DFARS, certain materials used in defense must be sourced from the United States or qualifying countries.

If you have specific molybdenum materials that are subject to DFARS, please let us know in advance and we will confirm.

At Heeger Materials Inc., we take this responsibility seriously. We adhere to all applicable laws and regulations, including Section 1502 of the Dodd-Frank Act. Our company operates with a strict code of ethics and is committed to only partnering with suppliers who share our dedication to responsible sourcing. We support the initiatives and programs aimed at promoting “conflict-free” supply chains and work diligently to ensure that our products meet these standards.

Heeger Materials Inc., established in 2016 in Colorado, USA, is a specialized supplier and manufacturer of tantalum and tantalum alloys. With extensive expertise in supply and export, we offer competitive pricing and customized solutions tailored to specific requirements, ensuring outstanding quality and customer satisfaction. As a professional provider of refractory metals, specialty alloys, spherical powders, and various advanced materials, we serve the research, development, and large-scale industrial production needs of the scientific and industrial sectors.
