Tantalum Wire

Tantalum Wire

Tantalum Wire

Standard: ASTM B365,  ASTM F560 (Medical Grade)

Material: R05200, R05400, R05252, R05255, R05240

  • Custom sizes and standard sizes in stock
  • Quick Lead Time
  • Competitive Price
5 star rating
5 star rating
5 star rating
5 star rating
5 star rating

Tantalum Wire is a high-performance material known for its excellent corrosion resistance, high melting point, and superior strength at elevated temperatures. Heeger Materials can supply high-quality tantalum wire with various specifications, offering customized solutions to meet specific requirements.

Get a Quote
Or email us at sales@heegermaterials.com.

Tantalum Wire Data Sheet

Reference:HMTA0005
Dimensions:0.004″ – 0.125″ Dia. x L
Standard:ASTM B365, ASTM F560 (Medical Grade)
Material:R05200, R05400, R05252, R05255, R05240
Purity:99%, 99.9%, 99.95%, 99.99%, 99.999%
Temper:Annealed or Unannealed

Tantalum Wire Applications

  • Tantalum wire can be used to manufacture anode leads for tantalum electrolytic capacitors.
  • Tantalum wire can be used to make tantalum yarn or tantalum mesh.
  • Tantalum wire can be used to make tantalum capacitors.
  • Medical tantalum wire can be used to suture nerves and tendons.

Tantalum and Tantalum Alloys

  • R05200, unalloyed tantalum, electron-beam furnace vacuum-arc melt, or both
  • R05400, unalloyed tantalum, powder-metallurgy consolidation.
  • R05255, tantalum alloy, 90 % tantalum, 10 % tungsten, electron-beam furnace of vacuum-arc melt, or both.
  • R05252, tantalum alloy, 97.5 % tantalum, 2.5 % tungsten, electron-beam furnace or vacuum-arc melt, or both.
  • R05240, tantalum alloy, 60 % tantalum, 40 % niobium, electron-beam furnace or vacuum-arc melt.

Tantalum Wire Packaging

The Tantalum Wire is carefully placed in wooden cases or cartons, with additional support from soft materials, to prevent shifting during transportation. This packaging method guarantees the integrity of the products throughout the delivery process.

Metal Packing

Tantalum Properties

ItemValue
Atomic number73
Crystal structureBody centred cubic
Electronic structureXe 4f¹⁴ 5d³ 6s²
Valences shown2,3,4,5
Atomic weight( amu )180.9479
Thermal neutron absorption cross-section( Barns )22
Photo-electric work function( eV )4.1
Natural isotope distribution( Mass No./% )180/ 0.012
Natural isotope distribution( Mass No./% )181/ 99.988
Atomic radius – Goldschmidt( nm )0.147
Ionisation potential( No./eV )1/ 7.88
Ionisation potential( No./eV )2/ 16.2
ItemValue
Material conditionUnannealed (Hard)
Material conditionAnnealed (Soft)
Poisson’s ratio0.342
Poisson’s ratio0.342
Bulk modulus( GPa )196.3
Bulk modulus( GPa )196.3
Tensile modulus( GPa )185.7
Tensile modulus( GPa )185.7
Hardness – Vickers( kgf mm⁻² )200
Hardness – Vickers( kgf mm⁻² )90
Tensile strength( MPa )760
Tensile strength( MPa )172-207
Yield strength( MPa )705
Yield strength( MPa )310-380
ItemValue
Electrical resistivity( µOhmcm )13.5@20@20°C
Superconductivity critical temperature( K )4.47
Temperature coefficient( K⁻¹ )0.0035@0-100°C
Thermal emf against Pt (cold 0C – hot 100C)( mV )0.33
ItemValue
Boiling point( °C )5425
Density( gcm⁻³ )16.6@20°C
ElementValue
Melting point( °C )2996
Latent heat of evaporation( J g⁻¹ )4165
Latent heat of fusion( J g⁻¹ )174
Specific heat( J K⁻¹ kg⁻¹ )140@25°C
Thermal conductivity( W m⁻¹ K⁻¹ )57.5@0-100
Coefficient of thermal expansion( x10⁻⁶ K⁻¹ )6.5@0-100°C

Download

Get A Quote

We will check and get back to you in 24 hours.

To customize your tantalum wire, please provide the following details:

  1. Diameter x Length
  2. Purity of the material
  3. Form (straight or coiled form)
  4. Quantity of the wire you need
  5. Alternatively, you can provide a drawing with your specifications.

Once we have these details, we can provide you with a quote within 24 hours.

We carry a wide variety of tantalum and tantalum alloy products in stock, and for these, there is generally no minimum order requirement. However, for custom orders, we typically set a minimum order value of $200. The lead time for stock items is usually 1-2 weeks, while custom orders usually take 3-4 weeks, depending on the specifics of the order.

DFARS (Defense Federal Acquisition Regulation Supplement) compliance is primarily concerned with the sourcing of materials for defense-related applications in the United States. According to DFARS, certain materials used in defense must be sourced from the United States or qualifying countries.

If you have specific tantalum materials that are subject to DFARS, please let us know in advance and we will confirm.

At Heeger Materials Inc., we take this responsibility seriously. We adhere to all applicable laws and regulations, including Section 1502 of the Dodd-Frank Act. Our company operates with a strict code of ethics and is committed to only partnering with suppliers who share our dedication to responsible sourcing. We support the initiatives and programs aimed at promoting “conflict-free” supply chains and work diligently to ensure that our products meet these standards.

Heeger Materials Inc., established in 2016 in Colorado, USA, is a specialized supplier and manufacturer of tantalum and tantalum alloys. With extensive expertise in supply and export, we offer competitive pricing and customized solutions tailored to specific requirements, ensuring outstanding quality and customer satisfaction. As a professional provider of refractory metals, specialty alloys, spherical powders, and various advanced materials, we serve the research, development, and large-scale industrial production needs of the scientific and industrial sectors.
