Tantal-Draht

Tantal-Draht

Tantal-Draht

Standard: ASTM B365,  ASTM F560 (Medical Grade)

Material: R05200, R05400, R05252, R05255, R05240

  • Kundenspezifische Größen und Standardgrößen auf Lager
  • Schnelle Vorlaufzeit
  • Konkurrenzfähiger Preis

Tantalum Wire is a high-performance material known for its excellent corrosion resistance, high melting point, and superior strength at elevated temperatures. Heeger Materials can supply high-quality tantalum wire with various specifications, offering customized solutions to meet specific requirements.

Oder senden Sie uns eine E-Mail an max@heegermaterials.com.

Tantalum Wire Data Sheet

Referenz:HMTA0005
Abmessungen:0.004″ – 0.125″ Dia. x L
Standard:ASTM B365, ASTM F560 (Medical Grade)
Material:R05200, R05400, R05252, R05255, R05240
Reinheit:99%, 99.9%, 99.95%, 99.99%, 99.999%
Temperament:Geglüht oder ungeglüht

Tantalum Wire Applications

  • Tantalum wire can be used to manufacture anode leads for tantalum electrolytic capacitors.
  • Tantalum wire can be used to make tantalum yarn or tantalum mesh.
  • Tantalum wire can be used to make tantalum capacitors.
  • Medical tantalum wire can be used to suture nerves and tendons.

Tantalum and Tantalum Alloys

  • R05200, unalloyed tantalum, electron-beam furnace vacuum-arc melt, or both
  • R05400, unalloyed tantalum, powder-metallurgy consolidation.
  • R05255, tantalum alloy, 90 % tantalum, 10 % tungsten, electron-beam furnace of vacuum-arc melt, or both.
  • R05252, tantalum alloy, 97.5 % tantalum, 2.5 % tungsten, electron-beam furnace or vacuum-arc melt, or both.
  • R05240, tantalum alloy, 60 % tantalum, 40 % niobium, electron-beam furnace or vacuum-arc melt.

Tantalum Wire Packaging

The Tantalum Wire is carefully placed in wooden cases or cartons, with additional support from soft materials, to prevent shifting during transportation. This packaging method guarantees the integrity of the products throughout the delivery process.

Metal Packing

Tantalum Properties

ArtikelWert
Ordnungszahl73
KristallstrukturKörperzentriert kubisch
Elektronische StrukturXe 4f¹⁴ 5d³ 6s²
Gezeigte Valenzen2,3,4,5
Atomgewicht (amu)180.9479
Thermischer Neutronenabsorptionsquerschnitt (Barns)22
Photoelektrische Arbeitsfunktion( eV )4.1
Natürliche Isotopenverteilung (Massen-Nr./%)180/ 0.012
Natürliche Isotopenverteilung (Massen-Nr./%)181/ 99.988
Atomradius - Goldschmidt( nm )0.147
Ionisierungspotenzial (Nr./eV)1/ 7.88
Ionisierungspotenzial (Nr./eV)2/ 16.2
ArtikelWert
Materieller ZustandUnannealed (Hard)
Materieller ZustandGeglüht (weich)
Poissonsche Zahl0.342
Poissonsche Zahl0.342
Elastizitätsmodul (GPa)196.3
Elastizitätsmodul (GPa)196.3
Zugspannungsmodul( GPa )185.7
Zugspannungsmodul( GPa )185.7
Härte - Vickers( kgf mm-² )200
Härte - Vickers( kgf mm-² )90
Zugfestigkeit( MPa )760
Zugfestigkeit( MPa )172-207
Streckgrenze( MPa )705
Streckgrenze( MPa )310-380
ArtikelWert
Elektrischer Widerstand (µOhmcm)13.5@20@20°C
Kritische Temperatur der Supraleitung( K )4.47
Temperaturkoeffizient( K-¹ )0.0035@0-100°C
Thermospannung gegen Pt (kalt 0C - heiß 100C)( mV )0.33
ArtikelWert
Siedepunkt( °C )5425
Dichte( gcm-³ )16.6@20°C
ElementWert
Schmelzpunkt( °C )2996
Latente Verdampfungswärme (J g-¹)4165
Latente Schmelzwärme ( J g-¹ )174
Spezifische Wärme( J K-¹ kg-¹ )140@25°C
Wärmeleitfähigkeit( W m-¹ K-¹ )57.5@0-100
Wärmeausdehnungskoeffizient( x10-⁶ K-¹ )6.5@0-100°C

Herunterladen

Angebot einholen

Wir werden das prüfen und uns innerhalb von 24 Stunden bei Ihnen melden.

To customize your tantalum wire, please provide the following details: Once we have these details, we can provide you with a quote within 24 hours.

We carry a wide variety of tantalum and tantalum alloy products in stock, and for these, there is generally no minimum order requirement. However, for custom orders, we typically set a minimum order value of $200. The lead time for stock items is usually 1-2 weeks, while custom orders usually take 3-4 weeks, depending on the specifics of the order.

DFARS (Defense Federal Acquisition Regulation Supplement) compliance is primarily concerned with the sourcing of materials for defense-related applications in the United States. According to DFARS, certain materials used in defense must be sourced from the United States or qualifying countries. If you have specific tantalum materials that are subject to DFARS, please let us know in advance and we will confirm.

Bei Heeger Materials Inc. nehmen wir diese Verantwortung ernst. Wir halten uns an alle geltenden Gesetze und Vorschriften, einschließlich Abschnitt 1502 des Dodd-Frank Act. Unser Unternehmen arbeitet nach einem strengen ethischen Kodex und verpflichtet sich, nur mit Lieferanten zusammenzuarbeiten, die unser Engagement für eine verantwortungsvolle Beschaffung teilen. Wir unterstützen die Initiativen und Programme zur Förderung “konfliktfreier” Lieferketten und arbeiten sorgfältig daran, dass unsere Produkte diese Standards erfüllen.

Heeger Materials Inc., established in 2016 in Colorado, USA, is a specialized supplier and manufacturer of tantalum and tantalum alloys. With extensive expertise in supply and export, we offer competitive pricing and customized solutions tailored to specific requirements, ensuring outstanding quality and customer satisfaction. As a professional provider of refractory metals, specialty alloys, spherical powders, and various advanced materials, we serve the research, development, and large-scale industrial production needs of the scientific and industrial sectors.
