Crisol de circonio

Zirconium Crucible Material Composition

Material	Composición química
	Zr+Hf	Sn	Fe	Cr	Ni	Hf	Nb
Zr 702	~99.5%	/	<0,05%	<0,05%	/	1~2.5%	/
Zr 704	~97.5%	1~2%	0.1~0.2%	0.1~0.2%	/	<4.5%	/
Zr 705	~95.5%	1~2%	<0,05%	<0,01%	/	<4.5%	2~3%
Zircaloy-2	~98%	1.2~1.7%	0.07~0.2%	0.05~0.15%	0.03~0.08%	<200ppm (para la industria nuclear)	/
Zircaloy-4	~98%	1.2~1.7%	0.07~0.2%	0.05~0.15%	<0,007%	<200ppm (para la industria nuclear)	/

Zirconium Crucible Mechanical Properties

Material	Tensile Strength, UltimateMpa (ksi)	Tensile Strength, YieldMpa (ksi)	Modulus of Elasticity Gpa (ksi)	Shear Modulus Gpa (ksi)	Elongation at Break
Zr 702	450 (65.3)	325 (47.1)	99.3 (14400)	36.2 (5250)	32%
Zr 704	530 (76.9)	360 (52.2)	99.3 (14400)	36.2 (5250)	22%
Zr 705	600 (87.0)	500 (72.5)	97.9 (14200)	34.5 (5000)	20.0%

Zirconium Crucible Production Process

• Materia prima: Seleccione alta pureza zirconium powder.
• Pulvimetalurgia: Mezclar con aglutinante y compactar en un tocho verde.
• Sinterización: Sinterización a alta temperatura para eliminar el aglutinante y aumentar la densidad.
• Tratamiento térmico: Recocido para aliviar la tensión y mejorar las propiedades.
• Tratamiento de superficies: Limpiar y pulir la superficie.

Zirconium Crucible Surface Finish

Depending on the intended applications, the zirconium crucible has three main surface finishes as follows:

• Negro: La superficie es "tal como se estampó" o "tal como se estiró", conservando una capa de lubricantes y óxidos de procesamiento.
• Limpio: La superficie se limpia químicamente para eliminar todos los lubricantes y óxidos.
• Suelo: The surface is centerless ground to remove all coating and to achieve precise dimensions control.

Zirconium Crucibles Safety Precautions For Use

1. After use, store the zirconium crucible in a dry place to prevent rainwater intrusion. Before use, gradually heat it to 500°C.
2. Add materials according to the crucible’s capacity, avoiding overpacking to prevent cracking from the thermal expansion of the metal.
3. When removing the metal solution, use a scoop rather than calipers. If calipers or other tools are necessary, ensure they match the shape of the crucible to prevent localized pressure that could shorten its lifespan.
4. The crucible’s service life depends on usage. Avoid direct exposure to an oxidizing flame, as this can cause oxidation of the crucible material, leading to premature wear.

Zirconium Crucible Applications

• Metal Melting: Zirconium crucibles are commonly used for melting precious metals (such as gold, silver, platinum, etc.) and metals with high melting points (such as tungsten, molybdenum, titanium, etc.) because of their good resistance to high temperatures and corrosion.
• Chemical Experiments: Zirconium crucibles are used in laboratories for high-temperature chemical reactions, especially those experiments that require resistance to strong acids and bases as well as high-temperature corrosive environments.
• Industria nuclear: Due to the good neutron permeability of zirconium, zirconium crucibles are also used in the nuclear industry, especially in the production and handling of nuclear fuel.

Zirconium Crucible Packaging

The Zirconium Crucible is carefully placed in wooden cases or cartons with additional support from soft materials to prevent any shifting during transportation. This packaging method guarantees the integrity of the products throughout the delivery process.
